BOXI Brake Master Cylinder for 1996-2003 GMC Safari | Replaces OE #102779
BOXI SKU#: BX06400003-1
$48.99
6 in stock
- Package Included
- 1 x Brake Master Cylinder
- Notes
- Instruction is not included. Professional installation is recommended
- Replaces OE Number
- MC390321, M390321, 18029952,130.66034, 132779, 13-2779, 102779, 10-2779 , F140671
- Condition
- New
- Master Cylinder Body Material
- Aluminum
Direct-fit BOXI replacement part compatible with 1996-2001 Chevrolet Astro Base, 2002-2003 Chevrolet Astro Base, 1996-2001 Chevrolet Astro LS, 2002-2003 Chevrolet Astro LS and additional configurations. Replaces OE / interchange part numbers: 102779, 130.66034, 132779, 18029952, F140671, M390321, MC390321, M900997. Ships from Montclair, CA across the United States with a 30-day return policy. Verify exact year, submodel, and engine in the Vehicle Fitment Guide before ordering.
Position & Application Summary
See Full Submodel & Engine Table →- 1996-2002 for Chevrolet Astro Mini Van 2WD & 4WD
- 1996-2002 for GMC Safari Mini Van 2WD & 4WD
| Weight | 2.89 lbs |
|---|---|
| Dimensions | 9.76 × 7.09 × 6.1 in |
| Brand | BOXI |
| Condition | New |
| Master Cylinder Body Material | Aluminum |
| Bleeder Kit Included | Yes |
| Reservoir Material | Plastic |
| Dust Boot Included | No |
| Reservoir Type | Integral |
| Pedal Rod Included | No |
| Reservoir Included | Yes |
| Brake Booster Included | No |
| Port 2 Thread Size (in) | 1/2 Inch |
| Bore Size (in) | 1.250 Inch |
| Bore Size (mm) | 31.75mm |
| Number Of Ports | 2 |
| Number Of Mounting Holes | 2 |
| Sensor Included | No |
| Gasket Or Seal Included | No |
| Warranty Terms | Two Year |
| Year | Make | Model | Submodel | Engine |
|---|---|---|---|---|
| 1996 – 2001 | Chevrolet | Astro | Base LS LT | V6 – 4.3L 262ci GAS MFI vin W type L35 – 2 valve OHV |
| 2002 – 2003 | Chevrolet | Astro | Base LS LT | V6 – 4.3L 262ci GAS MFI vin X type LU3 – 2 valve OHV |
| 1996 – 1997 | GMC | Safari | Base | V6 – 4.3L 262ci GAS MFI vin W type L35 – 2 valve OHV |
| 2003 | GMC | Safari | Base | V6 – 4.3L 262ci GAS MFI vin X type LU3 – 2 valve OHV |
| 1996 – 2001 | GMC | Safari | SL SLE SLT | V6 – 4.3L 262ci GAS MFI vin W type L35 – 2 valve OHV |
| 2002 | GMC | Safari | SL | V6 – 4.3L 262ci GAS MFI vin X type LU3 – 2 valve OHV |
| 2002 – 2003 | GMC | Safari | SLE SLT | V6 – 4.3L 262ci GAS MFI vin X type LU3 – 2 valve OHV |
| 1996 – 1998 | GMC | Safari | SLX | V6 – 4.3L 262ci GAS MFI vin W type L35 – 2 valve OHV |
OEM & Aftermarket Interchange Part Numbers
| Brand | OEM Part Number | Aftermarket Interchange Number |
|---|---|---|
| Chevrolet (OEM) | 18029952, F140671, 83-44034, E151332, R131879, MCA390321, 131.66034 | BX06400003-1, 102779, 130.66034 |
| Centric / Raybestos | 18029952, F140671, 83-44034 | 130.66034, MC390321, MC250400, MC140671 |
| Cardone | 18029952, F140671, 83-44034 | 20-2753 |
| Dorman | 18029952, F140671, 83-44034 | 174-799 |
| Aftermarket Interchange | 18029952, F140671, 83-44034 | 102779, 132779, M-86034, 390321, NM2779, 321323, 18M773, 13265 |
