Qty(2) BOXI 6826 Front Hood Lift Supports Gas Struts Shocks Spring Fit for Acura TL 2009 2010 2011 2012 2013 2014 Hood | Replaces SG326020 74145TK4A01 74145TK4A02 74149TK4A01 4B-897962 4B897962
BOXI SKU#: BXC300034082-2
$15.59
BOXI set of two front hood lift supports/gas struts for 2009-2014 Acura TL (Base, SH-AWD, Type-S). Replaces OE 74145TK4A01, 74145TK4A02, 74149TK4A01, 326020, 4B-897962. Verify fitment before ordering.
OE / Interchange Part Numbers: 4B897962, 4B897962W, 74145TK4A01, 74145TK4A02, 74149TK4A01, SG326020
184 in stock
Placement on Vehicle:Front Hood
Package Included:2pcs Front Hood Lift Supports
Fit: Acura TL 2009 – 2014 Hood
Extended Length [in] 16.08
Compressed Length [in] 9.40
Fits the following Acura TL Years:
2009-2014 | Base Sedan
2009-2014 | SH-AWD Sedan
2009-2014 | Type-S Sedan
| Weight | 1.05 lbs |
|---|---|
| Dimensions | 17.72 × 2.56 × 1.38 in |
| Brand | BOXI |
| Hardware Included: | No |
| Extended Length (in) | |
| Extended Length (mm): | 408 |
| Stroke (in): | 6.51 |
| Stroke (mm): | 165 |
| Compressed Length (in) | |
| Compressed Length (mm): | 245 |
| Force (Lbs) | |
| Force (Newtons) | 130 |
| Cylinder Diameter (in): | 0.71 |
| Cylinder Diameter (mm): | 18 |
| Rod Diameter (in): | 0.31 |
| Rod Diameter (mm): | 8 |
| Body Connection: | Ball Socket |
| Shaft Connection: | Ball Socket |
| Type: | Gas |
| Material | Steel |
| Unit of Measure: | Each |
| Warranty Terms | 5 Years |
| Interchange Part Number | 74145-TK4-A01, 74145-TK4-A02, TFS613406, 819-7077, E96826, Sg326020, E6826, AC0816596, 901884 |
