BOXI 2pcs Front Hood Lift Supports Struts Shocks Spring Fit for BMW 740i 1993-1995 | 740i 1997-2001 | 740iL 750iL 1993-2001 E38 Steel Hood Only | OE# SG402028 4540 51238150077
BOXI SKU#: BXC300002071-2
$19.48
BOXI Front Hood Lift Supports Struts for 1993-2001 BMW 740i, 740iL, 750iL E38. OE numbers: SG402028, 4540, 51238150077. Verify fitment before ordering.
OE / Interchange Part Numbers: 13685, 3293GE, 4540, 51238150077, 613813, 6199ZQ, 8194194, 95910, E95910, SG402028
42 in stock
Placement on Vehicle:Front Hood
Package Included:2pcs Front Hood Lift Supports
Extended Length [in] 12.80
Compressed Length [in] 8.80
Vehicle Location – Hood-Body Code: E38- Non Aluminum Hood)
Fits the following BMW Years:
1993-1995 | 740i Base Sedan 4-Door
1997-2001 | 740i Base Sedan 4-Door
1993-2001 | 740iL Base Sedan 4-Door
1993-2001 | 750iL Base Sedan 4-Door
| Weight | 1.2 lbs |
|---|---|
| Dimensions | 13.78 × 2.56 × 1.38 in |
| Brand | BOXI |
| Hardware Included: | No |
| Extended Length (in) | |
| Extended Length (mm): | 326 |
| Stroke (in): | 4.69 |
| Stroke (mm): | 120 |
| Compressed Length (in) | |
| Compressed Length (mm): | 206 |
| Force (Lbs) | |
| Force (Newtons) | 800 |
| Cylinder Diameter (in): | 0.87 |
| Cylinder Diameter (mm): | 22 |
| Rod Diameter (in): | 0.39 |
| Rod Diameter (mm): | 10 |
| Body Connection: | Ball Socket |
| Shaft Connection: | Ball Socket |
| Type: | Gas |
| Material | Steel |
| Unit of Measure: | Each |
| Warranty Terms | 5 Years |
| Interchange Part Number | 51238150077, 51 23 8 150 077, TFS613813, SG402028, 613813, 613816, SG404028, E95910, E4540, 819-4194, 510-839, 4540 |
| Year | Make | Model | Submodel | Engine |
|---|---|---|---|---|
| 1995 – 2001 | BMW | 740i | Base | V8 – 4.0L 3982cc GAS MFI type M60 – 4 valve DOHC |
| V8 – 4.4L 4398cc GAS MFI type M62 – 4 valve DOHC | ||||
| 1995 – 2001 | BMW | 740iL | Base | V8 – 4.0L 3982cc GAS MFI type M60 – 4 valve DOHC |
| V8 – 4.4L 4398cc GAS MFI type M62 – 4 valve DOHC | ||||
| 1993 – 2001 | BMW | 750iL | Base | V12 – 5.0L 4988cc GAS MFI type M70 – 2 valve SOHC |
| V12 – 5.4L 5379cc GAS MFI type M73 – 2 valve SOHC | ||||
| V12 – 5.4L 5379cc GAS MFI type M73N – 2 valve SOHC |
