BOXI 2pcs Liftgate Lift Supports Struts Shocks Gas Struts Shocks Springs Supports Fit for Ford Escape 2013-2016 Sport Utility 4-Door Liftgate-W/O Power Liftgate | SG104007 PM3775 CJ5Z78406A10A

BOXI SKU#: BXC300004310-2

$21.65

BOXI liftgate gas struts for Ford Escape 2013-2016 models without power liftgate. Fits various trims including base, hybrid, and limited. Replaces OE: SG104007, PM3775, CJ5Z78406A10A. Verify fitment before ordering.

OE / Interchange Part Numbers: 2B871433, 2B871433W, CJ5Z78406A10A, CJ5Z78406A11A, SG104007

  • 5 Years Warranty

102 in stock

Placement on Vehicle:Liftgate
Package included:2pcs Liftgate Lift Supports

Vehicle Location – Liftgate-W/O Power Liftgate Note supports are different lengths 6686L 6687R
Fits the following Ford Escape Years:
2013-2016 | Base Sport Utility 4-Door
2013-2016 | Hybrid Sport Utility 4-Door
2013-2016 | Limited Hybrid Sport Utility 4-Door
2013-2016 | Limited Sport Utility 4-Door
2013-2016 | S Plus Sport Utility 4-Door
2013-2016 | S Sport Utility 4-Door
2013-2016 | SE Plus Sport Utility 4-Door
2013-2016 | SE Sport Utility 4-Door
2013-2016 | SEL Sport Utility 4-Door
2015 | Sport Sport Utility 4-Door
2013-2016 | Titanium Sport Utility 4-Door
2013-2016 | Trend Advance Sport Utility 4-Door
2015 | Trend Sport Utility 4-Door
2013-2016 | XLS Sport Utility 4-Door
2013-2016 | XLT Sport Utility 4-Door

Weight 2.3 lbs
Dimensions 33.46 × 2.56 × 1.38 in
Brand

BOXI
Hardware Included:

No
Extended Length (in)

Extended Length (mm):

736
Stroke (in):

7.92
Stroke (mm):

200
Compressed Length (in)

Compressed Length (mm):

536
Force (Lbs)

Force (Newtons)

670
Cylinder Diameter (in):

0.87
Cylinder Diameter (mm):

22
Rod Diameter (in):

0.39
Rod Diameter (mm):

10
Body Connection:

Ball Socket
Shaft Connection:

Ball Socket
Type:

Gas
Material

Steel
Unit of Measure:

Each
Warranty Terms

5 Years
Interchange Part Number

6686, 819-7051, B96686, SG104007, SG904004, CJ5Z78406A11A, CJ5Z78406A10A, B6686, 900187
YearMakeModelSubmodelEngine
2013 – 2017FordEscapeS
S Plus		L4 – 2.5L 2488cc 152ci GAS MFI vin 7 – 4 valve DOHC
SE
Titanium		L4 – 1.5L 1499cc 91ci GAS DI Turbocharged vin D – 4 valve DOHC
L4 – 1.6L 1596cc 97ci GAS DI Turbocharged vin X – 4 valve DOHC
L4 – 2.0L 1999cc 122ci GAS DI Turbocharged vin 9 – 4 valve DOHC
L4 – 2.0L 1999cc 122ci GAS MFI Turbocharged vin 9 – 4 valve DOHC
L4 – 2.5L 2488cc 152ci GAS MFI vin 7 – 4 valve DOHC
2013 – 2014FordEscapeSE PlusL4 – 2.5L 2488cc 152ci GAS MFI vin 7 – 4 valve DOHC
2013FordEscapeSELL4 – 1.6L 1596cc 97ci GAS DI Turbocharged vin X – 4 valve DOHC
L4 – 2.0L 1999cc 122ci GAS MFI Turbocharged vin 9 – 4 valve DOHC
L4 – 2.5L 2488cc 152ci GAS MFI vin 7 – 4 valve DOHC
2015 – 2016FordEscapeTrendL4 – 2.0L 1999cc 122ci GAS MFI Turbocharged vin 9 – 4 valve DOHC
L4 – 2.5L 2488cc 152ci GAS MFI vin 7 – 4 valve DOHC
2017FordEscapeTrend AdvanceL4 – 2.0L 1999cc 122ci GAS DI Turbocharged vin 9 – 4 valve DOHC
L4 – 2.5L 2488cc 152ci GAS MFI vin 7 – 4 valve DOHC
