BOXI 4568 29.5inch 85lbs (380N) Gas Shock Strut Lift Support for Tonneau Cover Truck Cover Pickup Topper DIY Builds Basement Trap Door TV Cabinet etc
BOXI SKU#: BXC300054607-1
$18.35
BOXI Gas Shock Strut Lift Support for tonneau covers and truck toppers, replaces OE numbers 4568 and 95984. Verify fitment before ordering.
OE / Interchange Part Numbers: 1200M80BL, 30359, 30475, 4568, 713120, 7131201200, 716821, 8196319, 95984, B95984, SE1200M80BBL3158, SE1200M80BL
48 in stock
Placement on Vehicle:
Package Included:1pc Universal Lift Support
Tonneau Cover 4568 Universal Lift Supports
Extended Length [in] 29.50 Compressed Length [in] 17.50 Force (lbs) 85.00
Reference Number:95984, 030359, 030475, 1200M80BL, 2934, 30359, 4568, 713120, 7131201200, 713120-1200, 716821, 8196319, B95984, PM2048, RB8795984, SE1200M80BBL3158, SE1200M80BL, SE1200M80PS100, SNUG TOP 7131201200, SNUG TOP 713120-1200, SNUGTOP 7131201200, SNUGTOP 713120-1200
| Weight | 1.35 lbs |
|---|---|
| Dimensions | 33.46 × 2.56 × 1.38 in |
| Brand | BOXI |
| Hardware Included: | No |
| Extended Length (in) | |
| Extended Length (mm): | 749 |
| Stroke (in): | 12 |
| Stroke (mm): | 304 |
| Compressed Length (in) | |
| Compressed Length (mm): | 445 |
| Force (Lbs) | |
| Force (Newtons) | 378 |
| Cylinder Diameter (in): | 0.87 |
| Cylinder Diameter (mm): | 22 |
| Rod Diameter (in): | 0.39 |
| Rod Diameter (mm): | 10 |
| Body Connection: | Ball Socket Long Cup (Steel) Type=13mm=1/2"=.50" |
| Shaft Connection: | Ball Socket Long Cup (Steel) Type=13mm=1/2"=.50" |
| Type: | Gas |
| Material | Steel |
| Unit of Measure: | Each |
| Warranty Terms | 5 Years |
| Interchange Part Number | 95984, 1200M80BL, 2934, 30359, 30475, 4568, 713120, 7131201200, 713120-1200, 716821, 8196319, B95984, SE1200M80BBL3158, SE1200M80BL, SE1200M80PS100, SNUG TOP 7131201200, SNUG TOP 713120-1200, SNUGTOP 7131201200 |
