Free Shipping on All Orders — Plus Local Delivery & Pick-Up Options!

BOXI Qty(2) Dropgate Lift Supports Gas Shocks Springs Struts Fits for BMW F07 535i 535ix 550i 550ix 2008-2016 Hatchback / 51247200516 PM3372 SG302074

BOXI SKU#: BXC300002112-2

$21.99

BOXI Dropgate Lift Supports for BMW 535i, 550i, and GT Gran Turismo Hatchback models (2008-2016). Replaces OE 51247200516, 51247288721, PM3372, SG302074. Verify fitment before ordering.

  • 5 Years Warranty

17 in stock

Placement on Vehicle:Tailgate
Package Included:2pcs Tailgate Lift Supports

Fits the following vehicles:
Fits for BMW:
Fits for 2008-2016 535i Base Hatchback 4-Door Lower DropGate
Fits for 2008-2016 535i Gran Turismo Hatchback 4-Door Lower DropGate
Fits for 2010-2017 535i GT Base Hatchback 4-Door Lower DropGate
Fits for 2013 535i GT M Sport Hatchback 4-Door Lower DropGate
Fits for 2013 535i GT Top Hatchback 4-Door Lower DropGate
Fits for 2011-2017 535i GT xDrive Base Hatchback 4-Door Lower DropGate
Fits for 2008-2016 535ix Base Hatchback 4-Door Lower DropGate
Fits for 2008-2016 535ix Gran Turismo Hatchback 4-Door Lower DropGate
Fits for 2008-2016 550i Base Hatchback 4-Door Lower DropGate
Fits for 2008-2016 550i Gran Turismo Hatchback 4-Door Lower DropGate
Fits for 2010-2015 550i GT Base Hatchback 4-Door Lower DropGate
Fits for 2013 550i GT M Sport Hatchback 4-Door Lower DropGate
Fits for 2010-2017 550i GT xDrive Base Hatchback 4-Door Lower DropGate
Fits for 2008-2016 550ix Base Hatchback 4-Door Lower DropGate
Fits for 2008-2016 550ix Gran Turismo Hatchback 4-Door Lower DropGate

Interchangable OEM Numbers: 51247288721, 51 24 7 200 516, 51 24 7 288 721, 51247200516, PM3372, SG302074
Extended Length [Inches]: 14.69”
Compressed Length [Inches]: 9.45”
Package including:
2pcs Dropgate Lift Supports

Weight 0.88 lbs
Dimensions 15.75 × 2.56 × 1.38 in
Brand

BOXI
Hardware Included:

No
Extended Length (in)

Extended Length (mm):

373
Stroke (in):

5.32
Stroke (mm):

135
Compressed Length (in)

Compressed Length (mm):

238
Force (Lbs)

Force (Newtons)

560
Cylinder Diameter (in):

0.71
Cylinder Diameter (mm):

18
Rod Diameter (in):

0.31
Rod Diameter (mm):

8
Body Connection:

Ball Socket
Shaft Connection:

Ball Socket
Type:

Gas
Material

Steel
Unit of Measure:

Each
Warranty Terms

5 Years
Interchange Part Number

51247200516, 51247288721, 5B-612801, SG302074, V20-2883, URO-014150
YearMakeModelSubmodelEngine
2010 – 2017BMW535i GTBaseL6 – 3.0L 2979cc GAS DI Turbocharged type N55B30A – 4 valve DOHC
2013BMW535i GTM Sport
Top		L6 – 3.0L 2979cc GAS DI Turbocharged type N55B30A – 4 valve DOHC
2011 – 2017BMW535i GT xDriveBaseL6 – 3.0L 2979cc GAS DI Turbocharged type N55B30A – 4 valve DOHC
2010 – 2015BMW550i GTBaseV8 – 4.4L 4395cc GAS DI Turbocharged type N63B44B – 4 valve DOHC
V8 – 4.4L 4395cc GAS MFI Turbocharged type N63B44A – 4 valve DOHC
V8 – 4.4L 4395cc GAS MFI Turbocharged type N63B44B – 4 valve DOHC
2013BMW550i GTM SportV8 – 4.4L 4395cc 268ci GAS DI Turbocharged – 4 valve DOHC
2010 – 2017BMW550i GT xDriveBaseV8 – 4.4L 4395cc GAS DI Turbocharged type N63B44B – 4 valve DOHC
V8 – 4.4L 4395cc GAS MFI Turbocharged type N63B44A – 4 valve DOHC
V8 – 4.4L 4395cc GAS MFI Turbocharged type N63B44B – 4 valve DOHC
