Qty(2) BOXI Trunk Lift Supports Struts Shocks Gas Struts Shocks Springs Supports for Chevy Caprice 2011 2012 2013 2014 2015 2016 2017/for Pontiac G8 2008 2009 Sedan 4-Door | OE# SG430111 92213658 6556
BOXI SKU#: BXC300027063-2
$14.69
BOXI trunk lift supports for Chevy Caprice 2011-2017 and Pontiac G8 2008-2009 sedans. Replaces OE numbers SG430111, 92213658, 6556. Verify fitment before ordering.
OE / Interchange Part Numbers: 5113ZV, 92213658, 96556, E96556, SG430111
75 in stock
Placement on Vehicle:Trunk
Package Included:2pcs Trunk Lift Supports
Fits the following Chevrolet Caprice Years:
2011-2016 | Base Sedan 4-Door Trunk
2011-2017 | PPV Sedan 4-Door Trunk
Fits the following Pontiac G8 Years:
2008-2009 | Base Sedan 4-Door Trunk
2008-2009 | GT Sedan 4-Door Trunk
2008-2009 | GXP Sedan 4-Door Trunk
| Weight | 0.75 lbs |
|---|---|
| Dimensions | 13.78 × 2.56 × 1.38 in |
| Brand | BOXI |
| Hardware Included: | No |
| Extended Length (in) | |
| Extended Length (mm): | 292 |
| Stroke (in): | 3.74 |
| Stroke (mm): | 95 |
| Compressed Length (in) | |
| Compressed Length (mm): | 197 |
| Force (Lbs) | |
| Force (Newtons) | 516 |
| Cylinder Diameter (in): | 0.71 |
| Cylinder Diameter (mm): | 18 |
| Rod Diameter (in): | 0.31 |
| Rod Diameter (mm): | 8 |
| Body Connection: | Ball Socket |
| Shaft Connection: | Ball Socket |
| Type: | Gas |
| Material | Steel |
| Unit of Measure: | Each |
| Warranty Terms | 5 Years |
| Interchange Part Number | 819-8163, E96556, SG430111, 613992, SG330116, E6556, 92213658, 510-1254 |
| Year | Make | Model | Submodel | Engine |
|---|---|---|---|---|
| 2011 – 2017 | Chevrolet | Caprice | PPV | V6 – 3.6L 3564cc 217ci FLEX DI vin 3 type LFX – 4 valve DOHC |
| V8 – 6.0L 5967cc 364ci FLEX MFI vin 2 type L77 – 2 valve OHV | ||||
| 2008 – 2009 | Pontiac | G8 | Base | V6 – 3.6L 3564cc 217ci GAS MFI vin 7 type LY7 – 4 valve DOHC |
| GT | V8 – 6.0L 5967cc 364ci GAS MFI vin Y type L76 – 2 valve OHV | |||
| 2009 | Pontiac | G8 | GXP | V8 – 6.2L 6162cc 376ci GAS MFI vin W type LS3 – 2 valve OHV |
Related products
-
Warranty: 5 Years
- SKUBXC300002052-2
- BrandBOXI
- Hardware Included:No
- Extended Length (in)12.3
- Extended Length (mm):312
- Stroke (in):3.95
- Stroke (mm):100
- Compressed Length (in)8.35
- Compressed Length (mm):212
- Force (Lbs)144
- Force (Newtons)640
- Cylinder Diameter (in):0.75
- Cylinder Diameter (mm):19
- Rod Diameter (in):0.31
- Rod Diameter (mm):8
- Body Connection:Eyelet Hole
- Shaft Connection:Ball Socket
- Type:Gas
- MaterialSteel
- Unit of Measure:Each
- Warranty Terms5 Years
- Interchange Part Number51241908431, 51248171480, 51248236506, 51 24 1 908 431, 51 24 8 171 480, 51 24 8 236 506, TFS613989, 613989, SG402027, E95916, D4546, 901697, 819-4184, 510-843, 4546
-
Warranty: 5 Years
- SKUBXC300002028-2
- BrandBOXI
- Hardware Included:No
- Extended Length (in)10.1
- Extended Length (mm):256
- Stroke (in):3.88
- Stroke (mm):98
- Compressed Length (in)6.22
- Compressed Length (mm):158
- Force (Lbs)110
- Force (Newtons)490
- Cylinder Diameter (in):0.71
- Cylinder Diameter (mm):18
- Rod Diameter (in):0.31
- Rod Diameter (mm):8
- Body Connection:Eyelet Hole
- Shaft Connection:Eyelet Hole
- Type:Gas
- MaterialSteel
- Unit of Measure:Each
- Warranty Terms5 Years
- Interchange Part Number51241908431, 51242497679, 51 24 1 908 431, 51 24 2 497 679, TFS614313, 614313, SG402012, F4025, D95703, 901828, 901609, 51248410755, 510-150, 51 24 8 399 087, 4025
-
Warranty: 5 Years
- SKUBXC300001069-2
- BrandBOXI
- Hardware Included:No
- Extended Length (in)21.37
- Extended Length (mm):543
- Stroke (in):8.65
- Stroke (mm):220
- Compressed Length (in)12.72
- Compressed Length (mm):323
- Force (Lbs)70
- Force (Newtons)310
- Cylinder Diameter (in):0.71
- Cylinder Diameter (mm):18
- Rod Diameter (in):0.31
- Rod Diameter (mm):8
- Body Connection:Ball Socket
- Shaft Connection:Ball Socket
- Type:Gas
- MaterialSteel
- Unit of Measure:Each
- Warranty Terms5 Years
- Interchange Part NumberTFS611958, 80 634 04, 33684, 182192, 361011, 3B-033684, 7042, SG230133, 24465295
-
Warranty: 5 Years
- SKUBXC300002021-2
- BrandBOXI
- Hardware Included:No
- Extended Length (in)12.84
- Extended Length (mm):326
- Stroke (in):4.53
- Stroke (mm):115
- Compressed Length (in)8.31
- Compressed Length (mm):211
- Force (Lbs)130
- Force (Newtons)580
- Cylinder Diameter (in):0.71
- Cylinder Diameter (mm):18
- Rod Diameter (in):0.31
- Rod Diameter (mm):8
- Body Connection:Ball Socket
- Shaft Connection:Ball Socket
- Type:Gas
- MaterialSteel
- Unit of Measure:Each
- Warranty Terms5 Years
- Interchange Part Number51238174152, 819-8196, E96697, SG402042, E6697
