Qty(2) BOXI 6503 Rear Hatch Tailgate Liftgate Lift Supports Gas Struts Shocks Spring Dampers Fit for Hummer H2 2003 2004 2005 2006 2007 2008 2009 | Replace SG230052 SG230053 15230038 3B-4442TT 8196092
BOXI SKU#: BXC300054101-2
$20.99
BOXI rear hatch lift supports for 2003-2009 Hummer H2. Replaces OE numbers SG230052, SG230053, 15230038, 3B-4442TT, 8196092. Verify fitment before ordering.
OE / Interchange Part Numbers: 4441TY, 4442TT, 8196092, 95372, C95372, SG230052, SG230053
120 in stock
Placement on Vehicle:Liftgate
Package included:2pcs Liftgate Lift Supports
Extended Length [in] 26.25
Compressed Length [in] 19.25
These do not fit the H2T SUT Tonneau Cover
Fits the following Hummer H2 Years:
2005-2007 | Adventure Sport Utility 4-Door
2003-2009 | Base Sport Utility 4-Door
2005-2009 | Luxury Sport Utility 4-Door
2007 | Special Edition Sport Utility 4-Door
| Weight | 2.25 lbs |
|---|---|
| Dimensions | 27.56 × 2.56 × 1.38 in |
| Brand | BOXI |
| Hardware Included: | No |
| Extended Length (in) | |
| Extended Length (mm): | 667 |
| Stroke (in): | 7.47 |
| Stroke (mm): | 190 |
| Compressed Length (in) | |
| Compressed Length (mm): | 477 |
| Force (Lbs) | |
| Force (Newtons) | 710 |
| Cylinder Diameter (in): | 0.87 |
| Cylinder Diameter (mm): | 22 |
| Rod Diameter (in): | 0.39 |
| Rod Diameter (mm): | 10 |
| Body Connection: | Ball Socket |
| Shaft Connection: | Ball Socket |
| Type: | Gas |
| Material | Steel |
| Unit of Measure: | Each |
| Warranty Terms | 5 Years |
| Interchange Part Number | TFS610607, 819-6092, 610607, SG230053, SG230052, C95372, C6503, 901673, 8196092, 6503, 510-1249, 15230039, 15230038, 15171697, 15171696 |
| Year | Make | Model | Submodel | Engine |
|---|---|---|---|---|
| 2005 – 2009 | Hummer | H2 | Adventure Luxury | V8 – 6.0L 5967cc 364ci GAS MFI vin U type LQ4 – 2 valve OHV |
| V8 – 6.2L 376ci FLEX MFI type L9H – 2 valve OHV | ||||
| V8 – 6.2L 6162cc 376ci GAS MFI vin 8 type L92 – 2 valve OHV | ||||
| 2003 – 2009 | Hummer | H2 | Base | V8 – 6.0L 5967cc 364ci GAS MFI vin U type LQ4 – 2 valve OHV |
| V8 – 6.2L 6162cc 376ci FLEX MFI vin 2 type L9H – 2 valve OHV | ||||
| V8 – 6.2L 6162cc 376ci GAS MFI vin 8 type L92 – 2 valve OHV | ||||
| 2007 | Hummer | H2 | Special Edition | V8 – 6.0L 5967cc 364ci GAS MFI vin U type LQ4 – 2 valve OHV |
