BOXI 2pcs Trunk Lift Supports Struts Shocks Springs Compatible for Cadillac STS 2005 2006 2007 2008 2009 2010 2011 Sedan 4-Door Trunk | Replaces SG430103 6169 15861153

BOXI SKU#: BXC300051013-2

$22.41

BOXI trunk lift supports for 2005-2011 Cadillac STS sedan. Replaces OE SG430103 & 15861153. Verify fitment before ordering.

OE / Interchange Part Numbers: 134084, 15861154, 6169, 95103, E95103, SG430103

  • 5 Years Warranty

142 in stock

Placement on Vehicle:Rear Trunk
Package Included:2pcs Rear Trunk Lift Supports

Extended Length [in] 12.56
Compressed Length [in] 8.31

Fits the following Cadillac STS Years:

2005-2011 | Base Sedan 4-Door Trunk
2005 | Elegance Sedan 4-Door Trunk
2005-2011 | Platinum Sedan 4-Door Trunk
2005-2011 | V Sedan 4-Door Trunk

Weight 1.01 lbs
Dimensions 13.78 × 2.56 × 1.38 in
Brand

BOXI
Hardware Included:

No
Extended Length (in)

Extended Length (mm):

319
Stroke (in):

4.53
Stroke (mm):

115
Compressed Length (in)

Compressed Length (mm):

204
Force (Lbs)

Force (Newtons)

320
Cylinder Diameter (in):

0.71
Cylinder Diameter (mm):

18
Rod Diameter (in):

0.31
Rod Diameter (mm):

8
Body Connection:

Ball Socket
Shaft Connection:

Ball Socket
Type:

Gas
Material

Steel
Unit of Measure:

Each
Warranty Terms

5 Years
Interchange Part Number

6169, TFS613838, 613838, SG430103, E95103, E6169, 901889, 819-6546, 510-1223, 25751177, 25751176, 15861154, 15861153
YearMakeModelSubmodelEngine
2005 – 2011CadillacSTSBaseV6 – 3.6L 3564cc 217ci GAS DI vin D type LLT – 4 valve DOHC
V6 – 3.6L 3564cc 217ci GAS DI vin V type LLT – 4 valve DOHC
V6 – 3.6L 3564cc 217ci GAS MFI vin 7 type LY7 – 4 valve DOHC
V8 – 4.6L 281ci GAS MFI vin A type LH2 – 4 valve DOHC
2005CadillacSTSEleganceV8 – 4.6L 281ci GAS MFI vin A type LH2 – 4 valve DOHC
2008 – 2011CadillacSTSPlatinumV6 – 3.6L 3564cc 217ci GAS DI vin D type LLT – 4 valve DOHC
V6 – 3.6L 3564cc 217ci GAS DI vin V type LLT – 4 valve DOHC
V8 – 4.6L 281ci GAS MFI vin A type LH2 – 4 valve DOHC
2006 – 2009CadillacSTSVV8 – 4.4L 4371cc 267ci GAS MFI Supercharged vin D – 4 valve DOHC
