BOXI 2 Pcs Front Hood Lift Supports Struts Dampers for Lincoln Navigator 2003-2006 Hood | Replaces 6306 2L7416C826AC SG304075
BOXI SKU#: BXC300050001-2
$24.63
BOXI Front Hood Lift Supports Struts Dampers for Lincoln Navigator 2003-2006 models. Replaces OE numbers 6306, 2L7416C826AC, SG304075. Verify fitment before ordering.
OE / Interchange Part Numbers: 6306, 8196277, 95332, D95332, SG304075
72 in stock
Placement on Vehicle:Front Hood
Package Included:2pcs Front Hood Lift Supports
Extended Length [in] 18.68
Compressed Length [in] 11.85
Fits the following Lincoln Navigator Years:
2003-2006 | Base Sport Utility
2003-2006 | Luxury Sport Utility
2003-2006 | Ultimate Sport Utility
| Weight | 1.05 lbs |
|---|---|
| Dimensions | 21.65 × 2.56 × 1.38 in |
| Brand | BOXI |
| Hardware Included: | No |
| Extended Length (in) | |
| Extended Length (mm): | 474 |
| Stroke (in): | 6.91 |
| Stroke (mm): | 175 |
| Compressed Length (in) | |
| Compressed Length (mm): | 299 |
| Force (Lbs) | |
| Force (Newtons) | 390 |
| Cylinder Diameter (in): | 0.59 |
| Cylinder Diameter (mm): | 15 |
| Rod Diameter (in): | 0.24 |
| Rod Diameter (mm): | 6 |
| Body Connection: | Ball Socket |
| Shaft Connection: | Ball Socket |
| Type: | Gas |
| Material | Steel |
| Unit of Measure: | Each |
| Warranty Terms | 5 Years |
| Interchange Part Number | TFS612915, 1201-423537, 612915, SG304075, PC3233, D95332, D6306, 901517, 819-6277, 6306, 510-1039, 2L7Z 16C826-AA, 2L7416C826AC |
| Year | Make | Model | Submodel | Engine |
|---|---|---|---|---|
| 2003 – 2005 | Lincoln | Navigator | Base | V8 – 5.4L 330ci GAS MFI vin 5 – 3 valve SOHC |
| V8 – 5.4L 330ci GAS MFI vin R – 4 valve DOHC | ||||
| V8 – 5.4L 330ci GAS MPI – 4 valve DOHC | ||||
| 2006 | Lincoln | Navigator | Luxury | V8 – 5.4L 330ci GAS MFI vin 5 – 3 valve SOHC |
| 2004 – 2006 | Lincoln | Navigator | Ultimate | V8 – 5.4L 330ci GAS MFI vin 5 – 3 valve SOHC |
| V8 – 5.4L 330ci GAS MFI vin R – 4 valve DOHC | ||||
| V8 – 5.4L 330ci GAS MPI – 4 valve DOHC |
