BOXI Front Left or Right Wheel Hub and Bearing Assembly Fits for Chevrolet Equinox 2005-2006 / for Pontiac Torrent 2006 / for Saturn Vue 2002-2007 / (5 Lugs w/ABS) 513189
BOXI SKU#: BX03200002-1
$40.75
BOXI Front Left/Right Wheel Hub and Bearing Assembly for Chevy Equinox 2005-2006, Pontiac Torrent 2006, Saturn Vue 2002-2007 (5 Lugs w/ABS). Replaces OE 513189, BR930326. Verify fitment before ordering.
1 in stock
Placement on Vehicle:Front Left or Right
Package Included:1pc Wheel Hub and Bearing Assembly
Please kindly check the YEAR/MAKE/MODEL of your vehicle based on our product description to make sure this item is compatible.
Fitment:
Fits for Chevrolet Equinox 2005-2006
Fits for Pontiac Torrent 2006
Fits for Saturn Vue 2002-2007
Replacement OEM ( Original Equipment Part) Number: 513189 BR930326 10351823 WB13189
Package Included:1*Wheel hub bearing
| Weight | 8.59 lbs |
|---|---|
| Dimensions | 6.49 × 5.51 × 3.74 in |
| Brand | BOXI |
| Condition | New |
| Material | Steel |
| Driven Or Non-Driven | Driven |
| Gasket Or Seal Included | Yes |
| Bearing Included | No |
| ABS Sensor Included | Yes |
| Terminal Gender | Female |
| Flange Shape | Round |
| Wiring Harness Included | Yes |
| Greaseable | Yes |
| Bearing Type | Ball |
| Flange Diameter (in) | 2.780 Inch |
| Flange Diameter (mm) | 70.59mm |
| Flange Offset (in) | 1.653 Inch |
| Flange Offset (mm) | 42mm |
| Hub Pilot Diameter (in) | 3.590 Inch |
| Hub Pilot Diameter (mm) | 91.2mm |
| Flange Outside Diameter (in) | 5.910 Inch |
| Flange Outside Diameter (mm) | 150mm |
| Total Hub Diameter (in) | 5.910 Inch |
| Total Hub Diameter (mm) | 150mm |
| Hub Centerbore Diameter (in) | 4.530 Inch |
| Hub Centerbore Diameter (mm) | 115mm |
| Total Hub Height (in) | 4.530 Inch |
| Total Hub Height (mm) | 115mm |
| Flange Bolt Size (in) | 1.500 Inch |
| Flange Bolt Size (mm) | 38.2mm |
| Number Of Splines | 33 |
| Number Of Terminals | 1 |
| Number Of Lugs | 5 |
| Number Of Mounting Bolts To Knuckle | 3 |
| Number Of Lug Bolts Included | 5 |
| Number Of Flange Bolts Included | 5 |
| Lug Bolt Thread Size | M12-1.75 |
| Flange Bolt Thread Size | M12-1.50 |
| Warranty Terms | Two Year |
| Interchange Part Number | NT513189, 127-BR930326, 1411-44703, 1421-289674, WE60801, B-513189, 295-13189, SB513189, 730-0151, 104189, 104189HD, ZA-68BWKHS01E-Y-01, P513189, PS513189, BAR-5326, 70-513189, PSA58609, PSA59096, PSA59272, BHA53387, BHA53832, BHA53960, BKA17289, BKA21862, BKA52067, CSA64073, CSA64111, 040BR930326, WA513189, WA513189HD, WBR930326, WH513189, R513189, PT513189, PM513189, H513189, G513189, FW9189, FW333, 91-44703, 713189, 513189, 21990564, 10359823, 102034, 10014069 |
| Year | Make | Model | Submodel | Engine |
|---|---|---|---|---|
| 2005 – 2006 | Chevrolet | Equinox | LS LT | V6 – 3.4L 207ci GAS MFI vin F type LNJ – 2 valve OHV |
| 2006 | Pontiac | Torrent | Base LS LT | V6 – 3.4L 207ci GAS MFI vin F type LNJ – 2 valve OHV |
| 2002 – 2007 | Saturn | Vue | Base | L4 – 2.2L 2198cc 134ci GAS MFI vin D – 4 valve DOHC |
| V6 – 3.0L 3000cc 181ci GAS MFI vin B – 4 valve DOHC | ||||
| V6 – 3.5L 3471cc GAS MFI vin 4 – 4 valve SOHC | ||||
| V6 – 3.5L 3474cc GAS MFI – 4 valve SOHC | ||||
| V6 – 3.5L 3475cc GAS MFI vin 4 – 4 valve SOHC | ||||
| 2007 | Saturn | Vue | Green Line | L4 – 2.4L 2384cc 145ci FULL HYBRID EV-GAS MFI vin Z – 4 valve DOHC |
| 2004 – 2007 | Saturn | Vue | Red Line | V6 – 3.5L 3471cc GAS MFI vin 4 – 4 valve SOHC |
| V6 – 3.5L 3474cc GAS MFI – 4 valve SOHC |
